Ad9361rf agile transceiver

Product details:

·RF 2 integrating 12 bit DAC and ADC × 2 transceiver

·TX band: 47 MHz to 6.0 GHz

·RX band: 70 MHz to 6.0 GHz

·Support TDD and FDD operations

·Tunable channel bandwidth: < 200 kHz to 56 MHz

·Dual channel receiver: 6-way differential or 12-way single ended input

·Excellent receiver sensitivity with a noise figure of 2 dB (800 MHz LO)

·RX gain control

·Real time monitoring and control signals are used for manual gain

·Independent automatic gain control

·Dual transmitter: 4-way differential output

·High linearity broadband transmitter

· TX EVM：≤−40 dB

·TX noise: ≤− 157 DBM / Hz background noise

·TX monitor: dynamic range ≥ 66 dB, accuracy = 1 dB

·Integrated fractional N frequency synthesizer

·2.4 Hz maximum local oscillator (LO) step

·Multi device synchronization

·CMOS / LVDS digital interface
